MRL Elevator

Cost Effective and Energy Efficiency

Machine Roomless Elevator

MRL (Machine Room Less) Elevators are primary selections for projects with limited space or design that does not allow machine room construction. In addition, MRL elevators are ideal for medium-long travel with a consequential degree of reduction of energy and at the same time no extra space is required for the engine room.

The machine room-less elevators are designed considering the environment concerns by assimilating energy-efficient machines and noise controllers, saving the constructional space design making it environmentally friendly. Comparing it with gear load elevators, these elevators save upto 25% energy and 10% construction space. MRL elevators have overcome the conventional prerequisite of machine room by providing limitless possibilities in creation of elevators having comfort with optimal space utilization.

New Generation permanent magnet synchronous gearless traction machine.
Speed

Available Rated Speed

1.00 / 1.50 / 2 MPS

Max Travel Height

Max Travel Height

66 M

Available Rated Capacity

Available Rated Capacity

340 to 1768 kgs.

Max Person

Max Person

05 to 26 Passengers

CAPACITY Lift Well Cabin Inside Entry
Person Kgs. A B C D E
5 340 1600 1500 920* 1050 700
6 408 1650 1600 970* 1130 700
8 544 1850 1700 1120 1280 800
10 680 2000 1850 1270 1380 800
13 884 2100 2600 1070 2100 800/900
15 1020 2100 3000 1070 2400 800/900
20 1360 2300 3000 1320 2400 900/1000
26 1768 2450 3000 1620 2400 900/1000
MRL Elevator Drawing MRL Elevator Drawing MRL Elevator Drawing
