Autodoor Elevator

Reliable Comfort Comes From Reliable Technology

Autodoor Elevator

It sounds like Helix Elevators is offering advanced elevator systems designed with convenience and efficiency in mind. With the integration of fully automatic doors and modern lift controls, these elevators seem to prioritize user experience, focusing on high-speed operation, smooth travel, and precise leveling.

The two door types-Centre Opening and Telescopic Opening-offer flexibility to suit various building designs and space requirements. Center Opening doors are likely great for smaller spaces, while Telescopic Opening doors may be ideal for larger or more luxurious environments, providing wider access.

Available Rated Speed

Available Rated Speed

0.63 / 1.0 / 1.5 / 2 MPS

Max Travel Height

Max Travel Height

66 M

Available Rated Capacity

Available Rated Capacity

272 to 1360 kgs

Max Person

Max Person

04 to 20 Passengers

Multi-ray Entrance Protection System

Multi-ray Entrance Protection System

  • Operating by 94 crossed infrared beams
  • Enclosed power supply unit
  • Detecting area 20-1840 mm
  • Beeping on Passing by Detecting Range
Permanent Magnet (PM) Door Motor

Permanent Magnet (PM) Door Motor

The direct-drive PM door motor and the VVVF inverter realize efficient door opening and closing.

HOIST WAY PLAN ( AUTODOOR )

HOIST WAY PLAN ( AUTODOOR )

HOIST WAY ELEVATION DRAWING

HOIST WAY ELEVATION DRAWING

HOIST WAY MACHINE ROOM (Auto Doors)

LOAD CAR INSIDE LIFT WELL ENT. MACHINE ROOM SPEED MPS PIT DEPTH OVER HEAD
PER. WEIGHT WIDTH DEPTH WIDTH DEPTH WIDTH DEPTH HEIGHT
IN KG. A B C D E F G H
6 408 1100 1000 1900 1650 800 3000 3500 2500 OVER
1.5 		1600 4800
8 544 1300 1100 1900 1900 800 3200 3500 2500
10 680 1350 1300 1900 2000 800 3500 4000 2500
13 884 2000 1100 2500 1900 1000 4000 4200 2500
16 1088 2000 1300 2500 2000 1000 4500 4800 2500
20 1360 2000 1550 2500 2300 1000 5000 5000 2500
